    "document_type": "drawing",
    "drawing_no": "NE-1024-001",
    "revision": "C",
    "part_no": "NE-1024-001",
    "part_name": "MOUNTING BRACKET",
    "material": "A36 STEEL",
    "scale": "1:1",
    "tolerance_general": "ISO 2768-mK",
    "dimensions": [
        {
            "label": "Overall Length",
            "value": 120,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Overall Height",
            "value": 60,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Overall Width",
            "value": 60,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Step Height Lower",
            "value": 10,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Step Height Middle",
            "value": 40,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Left Edge Dimension",
            "value": 25,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Center Section Width",
            "value": 70,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Right Edge Dimension",
            "value": 25,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Through Hole Diameter",
            "value": 16,
            "unit": "mm",
            "tolerance": "THRU"
        },
        {
            "label": "Side Projection Width",
            "value": 12,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Side Projection Height",
            "value": 30,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Side Projection Base",
            "value": 10,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Counterbore Diameter",
            "value": 10.5,
            "unit": "mm",
            "tolerance": "THRU"
        },
        {
            "label": "Counterbore Depth",
            "value": 20,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Counterbore Taper",
            "value": 6,
            "unit": "mm",
            "tolerance": null
        },
        {
            "label": "Section Thickness",
            "value": 6,
            "unit": "mm",
            "tolerance": null
        }
    ],
    "drawn_by": "J. PATEL",
    "checked_by": "R. SINGH",
    "date": "2024-06-10",
    "company": "NORTHFIELD ENGINEERING LTD.",
    "surface_finish": "Ra 3.2 μm UNLESS OTHERWISE SPECIFIED",
    "notes": [
        "ALL DIMENSIONS ARE IN MILLIMETERS",
        "GENERAL TOLERANCES: ISO 2768-mK",
        "BREAK ALL SHARP EDGES 0.5 X 45°",
        "REMOVE ALL BURRS AND SHARP EDGES",
        "SURFACE FINISH: Ra 3.2 μm UNLESS OTHERWISE SPECIFIED",
        "THIS PART TO BE FREE FROM WARP AND TWIST"
    ],
    "_confidence": 0.98
}
